ELEMENT (4Z)

4Z

Share Link

ELEMENT (4Z)

4Z

Share Link
  • Material Type
    Seating Upholstery
    Material Sub-type
    Woven
    Price Grade
    B
    Image Shown
    Downroll
    Program
    Standard
    COM/Alliance Partner
    Other
  • Abrasion
    100,000
    Flammability
    TB117-2013
    Content
    24% RAYON
    Content
    76% POST CON RECYCLED POLY
    Lightfastness
    GRADE 4.5
    Image Shown
    Downroll
    ACT

    Abrasion!

    (resistance to damage from wear and rubbing)

    • Heavy-duty specification ASTM 4157-02 modified (#10 cotton duck); 30,000 double rubs Wyzenbeek method.
    • Heavy-duty specification ASTM D4966-98 (21 oz. weight); 40,000 cycles Martindale method.

    Fire Retardancy

    (resistance to burning)

    Seating upholstery meets California Technical Bulletin 117-2013

    Vertical fabrics meet ASTM E-84 Class A on Haworth panel systems

    Colorfastness to Light

    (fabric retains its color when exposed to light)

    All textiles meet AATCC option 1 or 3 - 2003, Class 4 minimum at 40 hours.

    Physical Properties

    (resistance to pilling, tearing and coming apart at the seams)

    Seating upholstery meets:

    • Brush pill ASTM D3511, 3-4 minimum
    • Breaking strength ASTM D5034-95 50lbs. minimum in warp and weft
    • Seam slippage ASTM D3597-02 D434-95 25 lbs. minimum in warp and weft.
  • Composition
    WOVEN
    Width
    54 inches
    Weight (Per Linear Yard)
    24 OZ
    Pattern Repeat H
    0.01 inches
    Pattern Repeat V
    0 inches
    Directional
    Yes
    Backing
    Yes
  • Finish Code Grade Application Program
